diamond wire sawing machine for profiling and squaring
We manufacture diamond wire sawing machines such as high-performance diamond wire sawing machine,compact diamond wire sawing machine,Mini diamond wire sawing machine,diamond wire sawing machine for profiling,diamond wire sawing machine for squaring.

PROFILING DIAMOND WIRE SAWING MACHINES FEATURES:
1). The main motor is powered by inverter to obtain the suitable wire speed according to the type of granite or marble.
2). The feeding movements are controlled by servo motors and NC system to cut various circular plates,columns and English letters.
3). Hydraulic tensioning system is applied to obtain stable tension for wire saw.
4). Adavanced man-machine interface and easy operation.
5). All kinds of protection devices guarantee the safety and reliability of the machine.


diamond wire sawing machine for profiling and squaring
Technical parameters of diamond wire sawing machine for profiling
Main power (kw) 11 15
Flywheels diameter (mm) 800 1000
Wire speed (m/s) 0-40 0-40
Wire length (mm) 13.5 17
Vertical stroke (mm) 1700 2300
Horizontal stroke (mm) 2000 3000
Max block to be cut (Width*Height) 2000*1500 3000*2100
Net weight (kg) 6500 8000

SQUARING DIAMOND WIRE SAWING MACHINES FEATURES:
1). The main motor is powered by inverter to obtain the suitable wire speed according to the type of granite or marble.
2). Hydraulic tensioning system is applied to obtain stable tension for wire saw.
3). Easy to manufacture and adjust the flywheels because of 4-flywheel structure.
4). All kinds of protection devices guarantee the safety and reliability of the machine.


Technical parameters of diamond wire sawing machine for squaring
Main power (kw) 15 15
Flywheels diameter (mm) 1000 1000
Wire speed (m/s) 0-40 0-40
Wire length (mm) 16.8 17.4
Vertical stroke (mm) 2300 2300
Max block to be cut (Width*Height) 3500*2100 3500*2400
Net weight (kg) 6500 8000
