Mini diamond wire sawing machine
We manufacture diamond wire sawing machines such as high-performance diamond wire sawing machine,compact diamond wire sawing machine,Mini diamond wire sawing machine,diamond wire sawing machine for profiling,diamond wire sawing machine for squaring.

MINI DIAMOND WIRE SAWING MACHINES FEATURES:
1)Compact and easy to move.
2)Very suitable for squaring all kinds of granite and marble blocks


    Mini diamond wire sawing machine
Technical parameters of Mini diamond wire sawing machine
Power supply 380V/50Hz
Driving power (kw) 7.5 7.5 11 11
Flywheels diameter (mm) 500 500 500 500
Wire saws speed (m/s) 0-36 0-36 0-36 0-36
Feeding power (kw) 0.37   0.37
Feeding speed (m/h) 0-30
Max moving distance (mm) 2500 2150 2500 2150
Max wire length (m) 10 10 15 15
Net weight (kg) 380 340 420 380

Mini diamond wire sawing machine
Technical parameters of Mini diamond wire sawing machine
Power supply 380V/50Hz
Driving power (kw) 7.5 11
Flywheels diameter (mm) 500 500
Wire saws speed (m/s) 0-36 0-36
Max moving distance (mm) 2150 2150
Max wire length (m) 10 15
Net weight (kg) 340 380
Diamond wire sawing machine
High-performance diamond wire sawing machine, Compact diamond wire sawing machine, Mini diamond wire sawing machine
diamond wire sawing machine for profiling and squaring
