Horizontal driller
We manufacture driller such as horizontal driller,cylinder driller,electric driller,pneumatic driller.

HORIZONTAL DRILLER FEATURES:
1)Rotation device is driven by motor, and feeding movement is driven by hand.
2)The feeding movement is very smooth with low noise and high stability, to keep the drilled hole straight.
3)This driller can only drill horizontal holes.


horizontal driller
Technical parameters of horizontal driller
Drilling depth (m) 30 30
Drilling diameter (mm) 75 75
Drilling speed (m/h) 3~4 3~4
Minimum water pressure (M Pa) 0.1 0.1
Stroke (m) 2.0 2.0
Feeding device Manual 0.37 KW
Rotation device 11 KW 11 KW
Net Weight (kg) 350 380
