diamond wire saw for granite quarries
We manufacture diamond wire saws which are widely used for granite quarries and granite mine block squaring. diamond wire saws are for low rigidity granite quarries,Mid-rigidity granite quarries,hard rigidity granite quarries,abrasive granite quarries,block squaring,granite profiling. Also we supply diamond wire saws for granite block squaring,granite profiling,granite quarries,marble block squaring,marble profiling,marble quarries,multi-wire machines.
diamond wire saw for granite quarries
diamond wire saw for granite quarries
diamond wire saw for granite quarries
diamond wire saw for granite quarries

Specification Beads/m Reinforcement
mm   R
Φ 8.8 40 rubber
Φ 11 40 rubber
Φ 11.5 38 rubber
Φ 11.5 40 rubber

Specification and performance parameters of diamond wire saws
Cutting material Line speed Cutting speed Wire life
  m/s /h

/m

Low rigidity granite 24-28 4-9 20-30
Mid rigidity granite 22-24 3-6 12-20
Hard granite 18-22 2-4 6-12
Abrasive granite 26-30 4-9 15-25
Specification and technical parameters of diamond beads
Specification (mm) Outer diameter (mm) Height of work layer (mm) Length (mm) manufacture tech
Φ 8.8 Φ 8.8 6.0 9.5 sintered
Φ 11 Φ 11 6.4 10 sintered
Φ 11.5 Φ 11.5 6.4 10/11.5 sintered
Diamond wire saw
Diamond wire saws are used for:
reinforced concrete, granite block squaring, granite profiling, granite quarries, marble block squaring, marble profiling
marble quarries, multi-wire machines, sandstone slate quarries
