driller
We manufacture driller such as horizontal driller,cylinder driller,electric driller,pneumatic driller.

DRILLER FEATURES:
1) compact in light weight and easy to assemble and transport.
2) controlled by hydraulic circuit and compressed air,with high drilling efficiency and low air consumption.
3) developed for granite,marble mine block quarrying,with high stability to keep the drilled hole straight.
4) high lifting capability,with special mechanized mounting and dismounting design to reduce labour intensity.
5) Driller with 20 pcs drill rods and one drill bit, complete set gross weight is 1000kg.



Technical parameters of driller
Drilling depth (m) 30
Drilling diameter (mm) 90~100
Drilling speed (m/h) 5~8
Working air pressure (M Pa) 0.5~0.7
Air consumption (/minute) 5~7
Stroke (m) 1.2
Motor (kw) 5.5
Lifting capability (kg) 1300
Main drillrig weight (kg) 350
hydraulic circuit weight (kg) 250
single oil pipe length (m) 5
Driller
cylinder driller, horizontal driller, electric driller, pneumatic driller
